PLM EUV Dual

● ISO Class 1 cleanliness with active self-clean air flow design.

● Automatic unlocks and locks SMIF outer pod door

● Lifts both inner and outer pod doors.

● Applies 80N force to Outer Pod door, per SEMI E152, during Unlocking and Locking of the Outer Pod door.

● All electrical system with field programmable application software

Smart RSP/EUV SMIF Handler

● Four programmable Interlock signals

● Inner pod Present Sensor

● Inner pod alignment sensors

● Info Pad sensors detect Pod Type - RSP 200 or EUV Pod

● Communication: Serial or Parallel, SECS optional.

● Meets SEMI E19.4, E84, E100, E117, E152, S2 and S8 standards and CE certified

● OHT Compatible

● Optional RFID reader/writer

● Optional Purge Available

● Unlock/Locks Standard 200mm SEMI E100 Reticle SMIF Pods (RSP)


Product Specifications
Size 150mm W x 150mm D x  6.35mm H
Dimension 363W x 420D x 700H mm
240 mm
Load Capacity 5.4kg
Pod Types

SEMI E152 RSP or E100

RSP

SEMI E19.4
100V/240VAC @ 1Amp  50/60Hz  Or 24 VDC (Option)
Weight 24kg without Pod
< 5 seconds
< 5 seconds
50,000 cycles
< 1 hour
Pod PIP sensor 1 set
Parallel/ Serial,EIA-RS232C(SECS I/II)
